D-108 Owner's Manual (Maintenance/Specifications)
137
Maintenance
Cleaning the exterior
* For normal cleaning, use a soft dry cloth.
For stubborn dirt, moisten a cloth in diluted detergent, wring it out firmly, and wipe the dirt off.
Then polish with a dry cloth. Never use solvents such as alcohol, thinner or benzene, since these will
damage the printing and finish of the exterior.
Specifications
Input/Output
INPUT (1 ~ 8)
Connector
: RCA pin jack (X 8)
Input impedance : 10kΩ or more
Input level : -10dBV
OUTPUT (1 ~ 8)
Connector
: RCA pin jack (X 8)
Load impedance : 10kΩ or more
Output level : -10dBV
DATA IN/OUT
Connector
: Optical (X 4)
Format : (1) IEC 958 Part 3 (=S/P DIF)
: (2) Alesis Proprietry Multi
Channel Optical Interface
(Either (1) or (2) is selected in
the Setup mode.)
MIDI IN/OUT/THRU
Connector
: DIN 5PIN (X 3)
Format : MIDI standard
SCSI
Connector
:D-sub 25 pin (X1)
PUNCH IN/OUT
Connector
: Ø6mm Phone jack (X 1)
(An optional FOOT SW Model
8051 can be connected.)
REMOTE
Connector
: D-sub 15PIN (X 1)
Recording/Reproducing
Recording medium : 3.5 inch, hard disk (E-
IDE type) or External SCSI
device
Recording format : FDMS-3*
Save/Load format : FDIO-1 Ver.2**
Sampling frequency : 44.1kHz/48kHz
Quantization : 16-bit linear
(Non expanded)
A/D: 20-bit 64-time, over sampling, Delta-Sigma
D/A: 20-bit 128-time, over sampling, Delta-Sigma
No. of recording track : 8 + 16 Additional tracks
(for 8track format)
Program No. : maximum 99 tunes
Crossfade : 10msec.
Recording/reproducing
frequency
: 20Hz ~ 20kHz
Dynamic range : 90dB
General
Dimensions : 482 (W) X 141 (H) X 381 (D)
mm, 3U size
* Including highest protrusion.
Weight : approx. 8.0kg (with REMOTE
controller)
Power supply : 120VAC 60Hz
: 230V~ 50/60Hz
Power consumption : approx. 33W
* Specifications and appearance are subject to
change without notice for product improvement.
* "Adat" and the
OPTICAL
symbol are trademarks of
Alesis Corporation.
* FDMS-3: Fostex Disk Management System-3.
* FDIO-1 Ver.2: Fostex Data In Out-1 Ver.2
