1. OPERATIONAL OVERVIEW

1-20

11. Enter longitude (setting range, 180

°

E-180

°

W, default setting, 125

°

00.000’W),

then push the [ENTER] knob.

12. Select START DATE & TIME, then press the EDIT soft key.
13. Enter start date and time, then push the [ENTER] knob.
14. Press the [MENU] key to close the menu.

Sounder

1. Select SOUNDER, then press the EDIT soft key.

SOUNDER

¡

SIMULATION 1

¡

SIMULATION 2

¤

LIVE

2. Select SIMULATION 1 (internally generated echoes) or SIMULATION 2

(network sounder-generated echoes), then push the [ENTER] knob.

Note 1: If the network sounder could not be found “Sounder source is not

found. Cannot get simulation data.” appears. And if the sounder is
not active, the message “Sounder is not active. Cannot get
simulation data.” is displayed. Check that the sounder is plugged in
and its signal cable is firmly fastened.

Note 2: The gain, shift, range and mode of the SIMULATION 1 mode picture

cannot be adjusted.

3. Press the [MENU] key to close the menu.
