5. CUSTOMIZING YOUR UNIT


5-9

5.3 Plotter

Setup

This paragraph provides the information necessary for setting up the plotter
display.

5.3.1 Navigation

options

Navigation options, for example, waypoint switching method, may be set on the
PLOTTER SETUP menu.

1. Show the plotter display, then press the [MENU] key open the main menu.
2. Press the PLOTTER SETUP soft key.

PLOTTER
SETUP

EDIT

D. BOX

RETURN

WAYPOINT SWITCHING ARRVL ALM CRCL

COURSE VECTOR

LINE

SET GOTO METHOD

1POINT

Plotter setup menu

Contents of plotter setup menu

Item Description Settings

Default

Setting

Waypoint
Switching

Chooses waypoint switching method.
See “switching waypoints” on page
3-50.

Perpendicular,
Arrvl Alm Crcl,
Manual

Arrvl Alm Crcl

Course
Vector

You may extend a line from the own
ship position to show ship’s course. It
may be a vector (length depends on
ship’s speed) or a simple line (course
bar).

Line, Vector, Off

Line

Set GOTO
Method

Sets the method by which to navigate
to a quick point. See “3.10.1 Navigating
to a quick point.”

1 Point, 35 Points,
35 Pts/Port
Service

1 Point

D. BOX
(soft key)

Sets up data boxes. See paragraph 5.5.
