5. CUSTOMIZING YOUR UNIT


5-5

Contents of radar display setup menu (con’t from previous page)

Item Description

Settings

Default

Setting

Background
Color

Chooses colors of background,
range rings and characters.
Effective when HUE soft key is set
for MANUAL.

Black/Green
Background: Black
Rings: Green
Characters: Green
Black/Red
Background: Black
Rings: Green
Characters: Red
Blue/White
Background: Blue
Rings: White
Characters: White
DK Blue/White
Background: Dark
Blue
Rings: Green
Characters: Red
White/Green
Background: White
Rings: Green
Characters: Green

Black/Green

Echo Color

Chooses echo color.

Yellow, Green,
Multi-color.
(Multi-color shows
echoes in red, yellow
or green in order of
descending
strength.)

Green

2ND Echo
Rejection

Reduces second-trace echoes. See
the paragraph “2.24 Suppressing
Second-trace Echoes.”

On, Off

Off

Watchman
Time

Sets watchman stand-by period.
For further details see the
paragraph “ 2.23 Watchman.”

5, 10, 20 minutes

5 minutes

Range Unit

Select unit of range measurement.

nm, km, sm

nm

Trail Mode

Sets echo trail reference.

Note:

Relative trail is available in all

presentation modes except true
motion. True trail is available in all
modes.

True:

Echo trails

plotted in actual
courses and speeds.
Requires compass
signal and speed
input.
Relative:

Echo trails

move relative to own
ship.

Relative
