6 Volt Battery Installation

• Lower the seat back. Make sure

the tabs on the front of the seat
are inserted into the slots in the
vehicle body.

Note: Make sure that the tabs on
the lock fastener are aligned with
the notches in the lock fastener
opening.
• Push down firmly on the seat

back to snap the seat into the
vehicle body.

5

• Rotate the lock fastener

1

/

4

turn

using a slotted screwdriver to lock
the battery compartment.

• Lift the seat back to make sure

the lock fastener is in the locked
position. Keep the lock fastener in
the locked position at all times to
prevent children from accessing
the batteries.

6

• Squeeze the tabs on each side

of the motor harness connector.

• Plug the battery connector into

the motor harness connector.

Note: If the battery connector will
not plug into the motor harness
connector, turn it over and try
again! Do not force the battery
connector into the motor harness
connector.

4

Motor Harness
Connector

Battery Connector

Lock Fastener

Lock Fastener

Lock Fastener
Opening

Top of Seat

Top View

30

Canopy Not Shown

Canopy Not Shown
