17
Assembly
• Insert the long tabs on the top of
a turn signal lens into the slots in
the front of the vehicle body. The
long tabs are at the top of the
turn signal lens.
• Push firmly on the bottom of
the turn signal lens to snap the
bottom tabs into the vehicle
body.
• Repeat this procedure to attach
the other turn signal lens to the
vehicle body.
16
Turn Signal
Lens
18
18
• Insert two #8 x 3 /
4
" screws into the
front bumper as shown.
• Tighten the screws with a Phillips
screwdriver. Do not over-tighten.
#8 x 3 /
4
" Screw – 2
Shown Actual Size
• Insert a hood latch into one of
the holes in the vehicle body,
near the hood area.
• Twist the base of the hood latch
1 /
4
turn to secure it in the vehicle
body.
• Repeat this procedure on the
other side of the hood area to
attach the other hood latch to
the vehicle body.
Hood Latch
Hole
Long
Tabs Long
Tabs
