Assembly
• Position the sport bar on its side
so that the sport bar ends curve
away from you.
• Position the canopy opposite the
sport bar with the netting facing
away from you.
• Slide the four canopy sleeves
onto the sport bar, as shown.
Canopy Sleeves
25
21
Seat
Tabs
Seat
Back Tabs
Slot
2
Tab
Notch in Body
Lock Fastener
BACK OF SEAT
3
PUSH
HERE
• With the seat at an angle, insert
the tabs on the front edge of the
seat into the slots in the foot-well
wall
.
• Push down firmly on the edge of
the seat above each tab to snap
the tabs into the slots
.
• Rotate the back of the seat
down to snap the seat back
tabs into the slots in the vehicle
body. Push down firmly on the
seat back.
Important Note: Make sure that the
tab on the lock fastener is aligned
with the notch in the vehicle body.
3
2
1
24
Canopy
Sleeves
Canopy
Sport Bar
1
