13
Assembly
• Bend the end of the telephone
cord so that it forms a “T”.
• Insert the end of the telephone
cord through the hole in the
dash, as shown.
• Pull up on the end of the
telephone cord to be sure it is
secure.
• Place the telephone in the
telephone holder with the
number pad facing out.
• Position the bottom edge of the
knob plate in the opening in the
dash.
• Snap the top of the knob plate
into the dash.
1 2 3
4 5 6
7 8
Dash
5
Knob Plate
Telephone Cord
• Fit the tabs on the dash into
the slots in the front of the
vehicle body.
• Insert two #10 x 1" screws through
the holes closest to the front of
the vehicle body and into the
vehicle body
.
• Insert two #10 x 1 /
2
'' screws through
the holes closest to the seating
area and into the holes in the
vehicle body
.
• Tighten each screw with a Phillips
screwdriver. Do not over-tighten.
2
1
1 2 3
4 5 6
7 8
Dash
Tab
6
Slots
Tab
#10 x 1" Screw – 2
Body
#10 x 1 /
2
" Screw – 2
Both Shown Actual Size
1 2
1
2
1
2
