FUJITSU TX120 - Manual (Page 17)

TX120 Operating Manual 17
Introduction Technical data
Mechanical values
Weight
Approx. 10 kg (depending on configuration).
Ventilation clearance
At least 200 mm on the front and rear.
Ambient conditions
Condensation during operation must be avoided!
Noise level
Horizontal operating position Upright operating position
Width 99 mm (195 mm with feet) 340 mm
Depth 399 mm 399 mm
Height 340 mm (360 mm with feet) 99 mm (104 mm with feet)
Environment class 3K2
Environment class 2K2 EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 15 °C ... 35 °C
Transport (2K2) -25 °C ... 60 °C
Humidity 10% ... 85%
Sound power level L
WAd
(ISO 9296) < 4.0 B (standby)
< 4.4 B (operation)
Sound pressure level at adjacent workstation
L
pAm
(ISO 9296)
< 28 dB (A) (standby)
< 31 dB (A) (operation)
