Installing and Maintaining the E1200i System
93
E1200i DC Chassis Physical Design
E1200i DC System Power Requirements
Parameter
Specifications
Height
36.75 inches (93.35 cm)
Width
17.40 inches (44.20 cm)
Depth (without cable management system)
21.25 inches (53.98 cm)
Chassis weight with factory-installed components
(backplane and air filter)
97 pounds (approx.) (44.00 kg)
Weight fully loaded (backplane, air filter, 2 fan trays, 10
SFMs, RPMs, and 14 line cards)
319 pounds (approx.) (144.70 kg)
Mounting
Attached rack mount brackets are factory set for front
mounting in a standard 19-inch rack.
Mounting brackets are adjustable for center and rear
mounting.
Optional brackets are available for front or center
mounting in a 23-inch rack or cabinet.
Rack clearance required
Front: 18 inches
Rear: 20 inches
Thermal Output
Maximum for fully loaded chassis
6850W (23,389 BTU/HR)
Minimum for chassis with one 48-port 1GE line card
1,450W (4,951 BTU/HR)
Parameter
Specifications
Maximum Power Consumption
6,850W
Input Voltage Range
200-240 VAC 50/60 Hz
Maximum Heat Dissipation
6,325W (21,598 BTU/HR)
Maximum Power Supply Input Current
16A per module
