88

Alarms

Power Supplies and Alarms

If a Power Supply fails while the E1200i is operating, the software generates a major alarm and an SNMP
trap, lights the major LED, and activates the audible alarm.

When a Power Supply fails, the software also records one alarm event for line cards, RPM, and SFM,
though each contains its own power source. The system generates one alarm event and SNMP trap
summarizing the Power Supply failure and the components affected.

Line Card

Hardware failure

major (red)

major

amber

no

Exceeds high temperature limit

major (red)

major

unlit

yes

Exceeds warning temperature
limit

minor (amber)

minor

green

yes

Individual interface fails

minor (amber)

reported

amber

2

no

RPM (Non-redundant Configuration with 1 RPM)

Exceeds high temperature limit

major (red)

major

unlit

yes

Exceeds warning temperature
limit

minor (amber)

minor

green

no

RPM fails but CP is ok

major (red)

major

amber

yes

SFMs (Redundant Configuration with 10 SFMs)

Exceeds high temperature limit

major (red)

major

unlit

yes

Exceeds warning temperature
limit

minor (amber)

minor

green

no

Any card fails

minor (amber)

minor

amber

no

Any card removed

minor (amber)

minor

unlit

no

8 SFMs (Non-Redundant Configuration)

Exceeds high temperature limit

major (red)

major

unlit

yes

Exceeds warning temperature
limit

minor (amber)

minor

green

no

Any card fails

major (red)

major

amber

yes

Any card removed

major (red)

major

unlit

yes

1 Event appears only in the show alarms command output.

2 The interface’s Link LED is unlit.

Table 14 Alarm Events and Reporting

Module

Alarm Event

Alarm LED

Reported in
event log

Status LED
on Module

Audible
Alarm?
