60
RPM Ports and Cables
Accessing the Auxiliary Port by Modem
You can access the auxiliary port using a dial-up modem using an RJ-45 to RJ-45 rollover cable and RJ-45
to DB-25 male DCE adapter (labeled “MODEM”).
lists the pin assignments.
Accessing the 10/100 Ethernet Management Port
Configure the 10/100 Ethernet management port, labeled 10/100 Ethernet on the primary RPM card in
order to obtain network access capability, such as downloading a runtime image onto your system. You can
connect this port to an Ethernet hub or FastEthernet port on a router.
Table 12 RJ-45 to DB-25 Adapter Pin (Modem) Assignments
E1200i
Auxiliary Port
RJ-45 to RJ-45 Rollover Cable
RJ-45 to DB-25
Modem Adapter
Modem
Signal
RJ-45 Pinout
RJ-45 Pinout
DB-45 Pinout
Signal
RTS
1
8
4
RTS
DTR
2
7
20
DTR
TxD
3
6
3
TxD
GND
4
5
7
GND
GND
5
4
7
GND
RxD
6
3
2
RxD
DSR
7
2
8
DCD
CTS
8
1
5
CTS
Table 13 10/100 Ethernet Management Port LEDs
Label
Description
L (Link)
Lit: Link is up
Unlit: No connection
A (Activity)
Lit: Activity on port
Unlit: No activity
