Finisar Surveyor User Manual
Page 410
B-14
Surveyor
User’s Guide
Table B-8. Standard Filter Templates, Token Ring
Filter Template
Description
Offset
Value
No. of
Filters
Used
MAC_Active_Monitor_Present
Collect all Active Moni-
tor Token Ring MAC
frames.
1
17
HEX 05
HEX 05
1
MAC_Beacon
Collect all Beacon
Token Ring MAC
frames.
1
17
HEX 02
HEX 02
1
MAC_Change_Parameters
Collect all Change
Parameters Token Ring
MAC frames.
17
HEX 0C
1
MAC_Claim_Token
Collect all “Claim Token”
Token Ring MAC
frames.
1
17
HEX 03
HEX 03
1
MAC_Duplicate_Address
Collect all Duplicate
Address Token Ring
MAC frames.
17
HEX 07
1
MAC_Initialize_Ring_Station
Collect all Initialize Ring
Station Token Ring
MAC frames.
17
HEX 0D
1
MAC_Lobe_Test
Collect all Lobe Test
Token Ring MAC
frames.
17
HEX 08
1
MAC_Poll_Error
Collect all Poll Error
Token Ring MAC
frames.
17
HEX 27
1
MAC_Remove_Ring_Station
Collect all Remove Ring
Station Token Ring
MAC frames.
17
HEX 0B
1
MAC_Report_Error
Collect all Report Error
Token Ring MAC
frames.
17
HEX 29
1
MAC_Report_Monitor_Error
Collect all Report Moni-
tor Error Token Ring
MAC frames.
17
HEX 28
1
