7-1
VIDEO PILOT DISPLAY, NAVIGATION
DATA DISPLAY
7.1 Video Pilot Display
Features
The video pilot display shows navigation information about your
destination, using a course-up presentation. To display the video pi-
lot display, press the [VIDEO PILOT] key. Figure 7-1 shows a typi-
cal video pilot display.
34
°
44.465’ N 355.6
°
95.59NM
135
°
21.289’ E 1.1KTS 0.01NM
2D 1.2
0.05 0.05
0.10
0.05
0.05
O 09:56
170
0.01NM
VTD
0.4 KTS
TTG
H M
ETA
:
North marker
(Arrow points to
true North)
Mark data Destination data
Figure 7-1 Sample video pilot display
Table 7-1 compares the features of the video pilot and plot displays.
