Figure 2-3 – FUJITSU M3000 User Manual
Page 24
2-4
SPARC Enterprise M3000 Server Service Manual • February 2011
FIGURE 2-3
Server (Rear View) (AC Power Supply Model)
Location No.
Component
1
Power supply unit (PSU)
2
PCIe slot
3
RCI port
4
USB port (for XSCF)
5
Serial port (for XSCF)
6
LAN port (for XSCF)
7
UPC port
8
Serial Attached SCSI (SAS) port
9
Gigabit Ethernet (GbE) port (for OS)
1
2
3
4
5
6
7
8
9
