1-2

SPARC Enterprise M3000 Server Service Manual • February 2011

FIGURE 1-1

Wrist Strap Connection Destination

Caution –

Do not connect the wrist strap cable to the conductive mat. Connect it

directly to the server.

The wrist strap and FRU must have the same level of potential.

Hard disk drive or fan unit:

Connect to one of two thumbscrews
on the front of the server.

FRU* other than hard disk drive and fan unit

Connect to either upper right on the front or upper left
on the rear of the server.

* FRU: Field Replaceable Unit
