3. MAINTENANCE, TROUBLESHOOTING
3-10
OUT OF RANGE! 0-65535 Invalid port number entered.
OUT OF RANGE! 10-30 Invalid NavNet port number entered.
OUT OF RANGE! BEAM:0-100 Invalid beam of ship entered.
OUT OF RANGE! CH-A(CH-B)
DOESN'T EXIST Invalid channel entered.
OUT OF RANGE! CPA:0-6.00 Invalid CPA range entered.
OUT OF RANGE! CREW:0-254 Invalid crew no. entered.
OUT OF RANGE! DAY Invalid day entered.
OUT OF RANGE! DRAUGHT:0-20.0
OUT OF RANGE! DRAUGHT:0-25.5 Invalid inland draught entered.
Invalid SOLAS draught entered.
OUT OF RANGE! HOUR:0-23* Invalid hour entered.
OUT OF RANGE!: INVALID
CHANNEL Invalid CH-NO. A or CH-NO. B entered.
OUT OF RANGE! LENGTH:0-800 Invalid ship's length entered.
OUT OF RANGE! MINUTE:0-59* Invalid minute entered.
OUT OF RANGE! NAV STATUS:0-15 Invalid nav status entered.
OUT OF RANGE!
PASSENGER:0-8190
Invalid no. of passengers entered.
OUT OF RANGE!
PERSONNEL:0-254 Invalid no. of personnel entered.
OUT OF RANGE! RETRY
TIMES:0-3. PRESS ANY KEY. Invalid no. of retry times entered.
OUT OF RANGE! TCPA:0-60 Invalid TCPA entered.
OUT OF RANGE! TUGBOAT:0-6 Invalid tugboat quantity entered.
OUT OF RANGE! TYPE NO.:10-99 Invalid cargo type entered.
OUT OF RANGE! ZONE:1-8 Invalid zone entered.
SEND MESSAGE UNSUCCESSFUL Message could not be sent.
TRANSPONDER WAS REBOOTED Transponder was rebooted.
* Error message displayed for both even if only one is out of range.
Note: Detection of RX malfunction
1) Detection of TDMA RX malfunction
Frequency error
PLL chip on receiver board generates lock or unlock signal for
synthesizer.
MPU watches and sets status flag which reflects data of ALR sentence.
ID 003 for RX1, ID 004 for RX2
2) Detection of DSC RX malfunction
General error
DSC Error (ID: 005) will happen in case of DSC MPU could not receive
format specifier of the data from DSC amplifier unless RSSI exists more
than 90 seconds.
