4-11
Desktop mount
For desktop mount, the optional desktop mount kit FP03-10201 (Code No.: 008-539-530) is
required.
Name Type Code No. Qty
Mounting bracket 19-023-3081-0 100-316-250 1
Self-tapping screw 5x20 000-802-081 4
Screw M4x10 000-881-145 4
1. Put the mounting bracket 19-023-3081 on the unit.
2. Fix the mounting bracket to the unit with four screws.
3. Mount the above assembly on a desktop with four self-tapping screws.
