4-1
4. OPTIONS
4.1 ARP Kit ARP-11
Necessary parts
Name: ARP kit
Type: ARP-11
Code no.: 008-523-050
Table 4-1 ARP-11 contents
Name Type Code No. Qty
ARP Board 18P9013 008-521-830 1
Pan head screw M3x6 C2700W 000-881-403 4
SQ9 000-801-850 1
Spacer*
SQ15 000-801-779 3
Spring washer* M3 C5191W 000-864-204 3
*Not used
1. Unscrew seven connecter nuts at the rear of the display unit.
2. Unfasten 15 bind screws (M3x10) to remove the display cover.
Removing the display unit cover
