1.2.3 Mounting the optional mounting bracket
A mounting bracket for fastening the antenna unit for MODEL1833C to a mast on a sailboat
is optionally available.
Mounting bracket 1
Type: OP03-92
Code No.: 008-445-070
Table 1-1 Mounting bracket contents
Type Code No. Qty
Hex. bolt M4X12 000-804-725 4
Hex. bolt M8X20 000-805-707 8
Mounting plate 03-018-9001-0 100-206-740 1
Support plate (1) 03-018-9005-0 100-206-780 1
Support plate (2) 03-018-9006-0 100-206-790 1
Bracket (1) 03-018-9002-1 100-206-751 1
Bracket (2) 03-018-9003-1 100-206-761 1
Fixing plate 03-018-9004-1 100-206-771 2
Assemble the mounting bracket and fasten it to a mast. Fasten the antenna unit to the
bracket.
