8. DISPLAYING PICTURE FROM
EXTERNAL RADAR
The picture from an external radar connected to the SUB DISPLAY termina can be
displayed on the FAR-2xx7 series display.
1. Use the trackball to set the pointer on the triangle in the ANTENNA box at the
upper left corner on the display.
2. Right click to show the ANT INFORMATION menu.
3. Select 8 SUB MONITOR then push the left button.
4. Select ON then push the left button.
5. Push the right button to close the menu.
6. Set the pointer on triangle in the ANTENNA box, and left-click several times to dis-
play SUB MONITOR to show the picture from the external radar.
ANT2 X-BAND
[ANT INFORMATION]
ANT NO 1
BAND : X-BAND
MODEL : 12
POS
: MAIN TOP
ANT NO 2
BAND : X-BAND
MODEL : 12
POS
: FORE
ANT NO 3
BAND :
MODEL :
POS
:
ANT NO 4
BAND :
MODEL :
POS
:
OWN RADAR NO: 1
8 SUB MONITOR
OFF/ON
9 INTER SW PRIORITY
OFF/ON
