6.4 GPS Buoy
With connection of a GPS radio buoy locator, the information (GPS buoy marker and
GPS buoy track) for up to seven GPS buoys may be shown on the radar screen. One
application of a GPS buoy is to tether it to a fishing net to monitor net position. Each
track may contain up to 20 track points. Marker color is available in red, green, blue,
yellow, light-blue, magenta and white.
Enabling, disabling GPS buoy information
1. Select the MENU box at the right side of the screen then push the left button.
2. Select [5 PLOTTER] then push the left button.
3. Select [8 GPS BUOY] then push the left button.
4. Select 2 GPS BUOY then push the left button.
5. Select ON or OFF as appropriate then push the left button.
6. Push the right button three times to close the menu.
Erasing all tracks of GPS buoys
1. Select the MENU box at the right side of the screen then push the left button.
2. Select [5 PLOTTER] then push the left button.
3. Select [8 GPS BUOY] then push the left button.
4. Select 3 ALL TRACK ERASE then push the left button.
5. Select YES then push the left button.
6. Push the right button three times to close the menu.
6
HEAD UP TB RM
MENU
ANT 1 X-BAND
PULSE S1
IR OFF
ES OFF
EAV OFF
AUTO RAIN
OFF
NM
/1 DISPLAY
RADAR GAIN
SEA AUTO
RAIN
TUNE AUTO
0. 9kt DRIFT
000. 0 ° T SET
34 ° 40. 649 N
135 ° 18. 303 E
+
TARGET
LIST
CU/TM
RESET
ALARM
ACK
GZ1
IL1
MARK
032. 0 ° T
RED
+
BRILL1
HL
OFF
EBL1 >280.9 ° T<
EBL2 240. 8 ° R TX
STBY
5. 60NM
ON
GZ2
ALARM1
ALARM2
VRM1
>3.682NM<
VRM2 5.221NM
000 010
020
030
040
050
060
070
080
090
100
110
120
130
140
150
160
170 180 190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
TRUE TRAIL OFF
25
22
19
ALIGN
26
TRIAL OFF
REF POINT
ANT POSN
01
02
GPS buoy
marker
GPS buoy
track
GPS buoy no.
TGT TRK
IND/MAG
1 BACK
2 GPS BUOY
OFF/ON
3 ALL TRACK ERASE
NO/YES
[GPS BUOY]
