12
2.4 Bearing Scale Format
The bearing scale can be displayed with numerical indications or 32 compass points.
1. Left-click the MENU box.
2. Select 2 [MARK] then push the left button.
3. Select 9 [EBL, VRM CURSOR SET] then push the left button.
4. Select 9 CURSOR BRG SCALE then push the left button.
5. Select 360
° or 32 POINTS as applicable.
6. Push the right button three times to close the menu.
000 010 020
030
040
050
060
070
080
090
100
110
120
130
140
150
160
170 180 190 200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
360
° 32 POINTS
N
NNE
NE
ENE
E
ESE
SE
SSE
S
SSW
SW
WSW
W
WNW
NW
NNW
[EBL, VRM, CURSOR SET]
1 BACK
2 EBL1
REL/TRUE
3 EBL2
REL/TRUE
4 VRM1
NM/SM/KM/kyd
5 VRM1
NM/SM/KM/kyd
6 CURSOR BEARING
REL/TRUE
7 CURSOR RANGE
NM/SM/KM/kyd
8 [ CURSOR SHAPE]
9 CURSOR BRG SCALE
360
°/32 POINTS
