24
Functions available with F1-F3 keys: OPERATION category
Item Function Settings
ECHO COLOR Select echo color. YELLOW, GREEN, WHITE,
MULTI
BACK COLOR Select background color. BLACK(GREEN characters),
BLACK(RED characters),
ECHO BLUE, BLUE, DARK
BLUE
RING Show/hide fixed range rings. OFF, ON
WATCH ALARM RESET Reset watch alarm.
ZOOM Enable/disable zoom.
DISPLAY SELECT Select display mode. RADAR, RADAR+PLOTTER,
PLOTTER
RADAR COMBINE Select dual-range display format. OFF, MIX, COMBINE
MOB Inscribe MOB mark.
USER DEFAULT Restore user defaults for [F1]-[F3].
(When "F-KEY" is selected at USER
DEFAULT in OPERATION (2/2) menu.
1. Set equipment as desired.
2. Display F1, F2 or F3 menu as appli-
cable.
3. Choose USER DEFAULT and long-
push (more than one second) the
left button.
4. To recall a setting, select F1, F2 or
F3 menu as applicable and choose
USER DEFAULTS.
The radar is then set to stand-by and
"USER DEFAULT" appears at the
bottom right corner.
TLL Output cursor-selected radar target’s
position to chart plotter.
ANCHOR WATCH Enable/disable anchor watch. OFF, ON
COLOR SHIFT Change track color according to color
arrangement.
ICON DISP Show/hide on-screen icons.
OWN TRK ALL ERASE Erase all tracks of your ship.
TGT TRK ALL ERASE Erase all tracks of all targets.
Functions available with F1-F3 keys: PICTURE category
Item Function
PICTURE 1 - 4 Select picture setup condition.
NEAR Optimum detection of targets in range of 3 nm or less
FAR Optimum detection of targets in range of 6nm or higher
NEAR BUOY Optimum detection of close-in buoys
FAR BUOY Optimum detection of distant buoys
ROUGH SEA Optimum radar setup in rough seas
SHIP Optimum detection of ships
NEAR BIRD Optimum detection of birds near your ship
FAR BIRD Optimum detection of distant birds
