21
Functions available with F1-F3 keys: ECHO category
Item Function Settings
PICTURE Select picture setup condition. PICTURE1, PICTURE2, PICTURE3,
PICTURE4, NEAR, FAR, NEAR BUOY,
FAR BUOY, ROUGH SEA, SHIP,
HARBOR
1
, COAST
1
, NEAR BIRD
2
, FAR
BIRD
2
1
10 kW/25 kW
2
50 kW/60 kW
IR Enable/disable interference
rejector. OFF, 1, 2, 3
ES Enable/disable echo stretch. OFF, 1, 2, 3
EAV Enable/disable echo averaging. OFF, 1, 2, 3
NOISE REJ Enable/disable noise rejector. OFF, ON
ANT SELECT Select antenna unit.
PULSE LENGTH Select pulse length. 10 kW/25 kW models
0.125, 0.25, 0.5 NM: S1
0.75, 1, 1.5, 2 NM: S1, S2, M1
3, 4 NM: S2, M1, M2, M3
6, 8 NM: M1, M2, M3, L
12, 16, 24 NM: M2, M3, L
32, 48, 96, 120 NM: L
50 kW/60 kW models
0.125, 0.25, 0.5 NM: S
0.75, 1, 1.5, 2 NM: S, M1
3, 4 NM: M1, M2
6, 8, 12, 16, 24 NM: M2, L
32, 48, 96, 120 NM: L
A/C SEA SELECT Select A/C SEA adjustment
method. AUTO, MANUAL
AUTO RAIN SELECT Enable/disable AUTO RAIN. OFF, 1, 2, 3, 4
TUNE SELECT Select tuning method. AUTO, MANUAL
VIDEO CONTRAST1 Set Video Contrast1. 1, 2, 3, 4
VIDEO CONTRAST2 Set Video Contrast2. A, B, C
ANT HEIGHT Select antenna height (above the
waterline). 5, 7.5, 10, 15, 20, 30, 35, 40, 45, more
than 50 (m)
SEA CONDITION Set sea condition. 1, 2, 3, 4, 5
2ND ECHO REJ Enable/disable second-trace
echo rejector. OFF, ON
PM Enable/disable performance
monitor. OFF, ON
SART Enable/disable set up for
optimum detection of SART. OFF, ON
WIPER Enable/disable wiper. OFF, 1, 2
ECHO AREA Select echo area configuration. CIRCLE, WIDE, ALL
