18
4. FUNCTION KEYS (F1 - F4)
4.1 F1, F2 and F3 Keys
The F1, F2 and F3 keys can be used to automate complex or repetitive tasks. Each
key may be programmed with ten functions. Simply press a key to execute program
assigned.
Operating F1, F2 and F3 keys
The table below shows the default functions of the F1, F2 and F3 keys.
1. Press F1, F2 or F3 key. For example, press the F1 key.
2. Select function desired then push the left button. Programmed function is then exe-
cuted.
3. To continue, repeat step 2.
4. Push the right button to close the menu.
Default functions of F1, F2 and F3 keys
F1 key F2 key F3 key
1. PICTURE 1. OS TRAIL 1. OWN TRACK OFF/ON
2. IR 2. BRILL 2. OWN TRACK COLOR
3. ES 3. DISP ARP 3. TGT TRACK OFF/ON
4. EAV 4. DISP AIS 4. TGT TRACK COLOR
5. PULSE LENGTH 5. DISPLAY SELECT 5. OWN TRACK DISPLAY
6. WIPER 6. ICON DISP 6. TARGET TRACK DISPLAY
7. ECHO AREA 7. PICTURE1 7. GPS BUOY DISPLAY
8. NO FUNCTION 8. PICTURE2 8. MAP MARK COLOR
9. NO FUNCTION 9. PICTURE3 9. DISP WPT NO.
0. NO FUNCTION 0. PICTURE4 0. DISP WPT NAME
[F1 EXECUTE]
1 PICTURE
2 IR
3 ES
4 EAV
5 PULSE
LENGTH
6 WIPER
7 ECHO AREA
8 NO FUNCTION
9 NO FUNCTION
0 NO FUNCTION
