Table 4.2 Transfer rate of each zone
For MPE3064AT, MPE3136AT, MPE3273AT
Zone 0 1 2 3 4 5 6 7
Cylinder 0
to
410
411
to
2320
2321
to
3110
3111
to
4600
4601
to
6060
6061
to
7200
7201
to
8260
8261
to
9970
Transfer rate
[MB/s]
29.80 28.63 28.09 27.06 26.01 25.14 24.31 22.90
Zone 8 9 10 11 12 13 14
Cylinder 9971
to
11180
11181
to
11850
11851
to
12900
12901
to
13830
13831
to
14970
14971
to
16130
16131
to
16347
Transfer rate
[MB/s]
21.85 21.26 20.29 19.43 18.34 17.18 16.13
For MPE3102AT, MPE3170AT, MPE3204AT
Zone 0 1 2 3 4 5 6 7
Cylinder 0
to
1260
1261
to
2280
2281
to
3190
3191
to
4100
4101
to
4880
4881
to
6315
6316
to
7680
7681
to
8760
Transfer rate
[MB/s]
30.43 29.80 28.63 28.62 28.09 27.06 26.01 25.14
Zone 8 9 10 11 12 13 14
Cylinder 8761
to
10030
10031
to
11370
11371
to
12510
12511
to
13060
13061
to
14125
14126
to
15410
15411
to
16347
Transfer rate
[MB/s]
24.06 22.90 21.85 21.33 20.29 19.00 17.18
The MPU transfers the data transfer rate setup data (SDATA/SCLK) to the RDC that includes
the time base generator circuit to change the data transfer rate.
