Table 1.3 Current and power dissipation
Typical RMS current (*1) [mA]
+12 V +5 V
Model MPE3064
AT
MPE3102/
MPE3136
AT
MPE3170/
MPE3204
AT
MPE3273
AT
All Models MPE3064
AT
MPE3102/
MPE3136
AT
MPE3170/
MPE3204
AT
MPE3273
AT
Spin up 1500
1800 peak
1500
1800 peak
1600
1800 peak
1600
1800 peak
572
592 peak
21.1 21.1 22.3 22.3
Idle (Ready) (*3) 140 170 200 240 340 3.4 3.7 4.1 4.6
R/W (On Track) (*4) 180 210 240 280 620 5.3 5.6 6.0 6.5
Seek (Random) (*5)
Seek/W/R
300 330 360 400 620 6.7 7.1 7.4 7.9
Standby 7 7 7 7 185 1.0 1.0 1.0 1.0
Sleep 7 7 7 7 185 1.0 1.0 1.0 1.0
*1 Current is typical rms except for spin up.
*2 Power requirements reflect nominal values for +12V and +5V power.
*3 Idle mode is in effect when the drive is not reading, writing, seeking, or executing any commands. A portion of the R/W circuitry is powered
down, the spindle motor is up to speed and the Drive ready condition exists.
*4 R/W mode is defined as 50% read operations and 50% write operations on a single physical track.
*5 Seek/W/R mode is defined as 33% seek operations, 33% write operations and 33% read operations.
Typical Power (*2) [watts] Mode of Operation
