2. PLOTTER DISPLAY
2-3
2.2 Cursor
2.2.1 Turning on the cursor, shifting the cursor
Press the cursor pad to turn the cursor on, and the cursor appears at the own
ship’s position. Operate the cursor pad to shift the cursor. The cursor moves in
the direction of the arrow or diagonal pressed on the cursor pad.
Cursor state determines what data is shown in the NAVDATA window. This
window can be enabled or disabled by pressing the NAVDATA ON soft key.
NAVDATA window
Also, when the cursor is placed on own ship’s position, its data is shown as
follows.
FIX 3D
SOG COG
33 37.125N
118 48.428W
1.00 kts 007 M
Own ship’s position data window
2.2.2 Moving the cursor to the center of the screen
Press the CENTER soft key to return the cursor to the screen center.
