Technical Reference Guide

The DMA logic is accessed through two types of I/O mapped registers; page registers and
controller registers.

4.4.2.1

DMA Page Registers


The DMA page register contains the eight most significant bits of the 24-bit address and works in
conjunction with the DMA controllers to define the complete (24-bit) address for the DMA
channels. Table 4-8 lists the page register port addresses.

Table 4-8. DMA Page Register Addresses

Table 4-8.

DMA Page Register Addresses

DMA Channel

Page Register I/O Port

Controller 1 (byte transfers)
Ch 0
Ch 1
Ch 2
Ch 3


087h
083h
081h
082h

Controller 2 (word transfers)
Ch 4
Ch 5
Ch 6
Ch 7


n/a
08Bh
089h
08Ah

Refresh

08Fh [see note]

NOTE:
The DMA memory page register for the refresh channel must be
programmed with 00h for proper operation.


The memory address is derived as follows:

24-Bit Address - Controller 1 (Byte Transfers)
8-Bit Page Register

8-Bit DMA Controller

A23..A16 A15..A00

24-Bit Address - Controller 2 (Word Transfers)
8-Bit Page Register

16-Bit DMA Controller

A23..A17

A16..A01, (A00 = 0)



Note that address line A16 from the DMA memory page register is disabled when DMA
controller 2 is selected. Address line A00 is not connected to DMA controller 2 and is always 0
when word-length transfers are selected.

By not connecting A00, the following applies:

♦ The size of the the block of data that can be moved or addressed is measured in 16-bits

(words) rather than 8-bits (bytes).

♦ The words must always be addressed on an even boundary.

Compaq D315 and hp d325 Personal Computers

Featuring the AMD Athlon XP Processor

Second Edition - April 2003

4-19
