Figure 3-2 illustrates the internal architecture of the Athlon XP processor.
FPU
Branch
Prediction
Integer
ALUs 1-3
FSB
I/F
256-K
L2
Cache
128-K
L1
Cache
128-bit
Integer
FPU
CPU
3-Way Instruction
Decoders
Athlon XP Processor
Athlon XP Type Core Speed Voltage Max. Current Max. Power
Model 6 1500+ 1333 MHz 1.75 VDC 34.3 A 60.0 W
Model 6 1600+ 1400 MHz 1.75 VDC 35.9 A 62.8 W
Model 6 1700+ 1467 MHz 1.75 VDC 36.6 A 64.0 W
Model 8 1700+ 1467 MHz 1.50 VDC 32.9 A 49.4 W
Model 6 1800+ 1533 MHz 1.75 VDC 37.7 A 66.0 W
Model 8 1800+ 1533 MHz 1.50 VDC 34.0 A 51.0 W
Model 6 1900+ 1600 MHz 1.75 VDC 38.9 A 68.0 W
Model 8 1900+ 1600 MHz 1.50 VDC 35.0 A 52.2 W
Model 6 2000+ 1667 MHz 1.75 VDC 40.0 A 70.0 W
Model 8 2000+ 1667 MHz
“
“
1.60 VDC
1.65 VDC
1.60 VDC 37.7 A
36.5 A
38.3 A 60.3 W
60.3 W
61.3 W
Model 6 2100+ 1733 MHz 1.75 VDC 41.1 A 72.0 W
Model 8 2100+ 1733 MHz 1.60 VDC 38.8 A 61.1 W
Model 8 2200+ 1800 MHz
“
1.60 VDC
“
41.2 A
39.3 A 67.9 W
62.8 W
Model 8 2400+ 2000 MHz 1.65 VDC 41.4 A 68.3 W
Model 8 2600+ 2133 MHz
2083 MHz 1.65 VDC
“
41.4 A
“
68.3 W
“
Model 8 2800+ 2083 MHz 1.65 VDC 41.4 A 68.3 W
Model 8 3000+ 2167 MHz 1.65 VDC 45.0 A 74.3 W
Figure 3–2. AMD Athlon XP Processor Internal Architecture and Key Statistics.
The Athlon XP processor uses 0.13 micron technology that yields lower power requirements for a
given processing speed. The system board supports the unit types listed in Figure 3-2.
The Athlon XP processor uses a 133-MHz (on D315 systems) or 166-MHz (on d325 systems)
clock signal for the front side bus. Data transfers are qualified on the both the rising and falling
edge of the clock cycle, effectively doubling the data throughput rate to 266- and 333-MHz.
