Dimensions and Clearances
The following clearances are recommended for the appliance.
• Additional clearances should be considered for ease of installation and servicing.
• Additional clearances should be considered on all sides of the dryer to reduce noise transfer.
Installation Spacing for Recessed Area or Closet Installation
-
Description
Dimension/Clearance
A
Upper Ventilation Opening
2
48 sq. in. (310 cm
2
)
B
Lower Ventilation Opening
2
24 sq. in. (155 cm
2
)
C
Distance to Ventilation Opening
2
3
″
(76 mm)
D
Overhead Cabinet Depth
1
14
″
(356 mm)
E
Distance to the Overhead Cabinet/Shelf
2
18
″
(457 mm)
F
Front Clearance
1
″
(25 mm)
G
Depth
29 3/4
″
(756 mm)
H
Back Clearance
2
5
″
(127 mm)
I
Side Clearance
2
1
″
(25 mm)
J
Width
27
″
(686 mm)
K
Height of Cabinet Opening
39
″
(989 mm)
