ROI Series Mini-Converter v1.7 42 www.aja.com
RGB Range
• Full
• SMPTE
Reference Source
• Free Run
• Ext Ref
Reference Input
• Supported reference video inputs include
• 1080i tri-level sync
• 1080p tri-level sync
• 720p tri-level sync
• 625i Color Black
• 525i Color Black
• 75-ohm terminating
Video Input
• 1x DVI input connector (with embedded audio, up to 8 channels)
Video Outputs
• DVI
• 1x DVI loop through connector (with embedded audio, up to 8 channels)
• SDI
• 3G-SDI, SMPTE-259/292/424, 1x BNC
Audio Inputs
• 1x Analog 3.5mm TRS, 2-Channel
• DVI embedded audio, 24-bit, 8-channel
Audio Output
• SDI embedded audio, 24-bit, 2-channel or 8-channel
User Controls
• USB port used with supplied cable and Mini-Config software application to
configure device via Mac or Windows
Size (w x d x h)
• 5.77" x 4.02" x 0.9" (146.56 x 102.11 x 22.86 mm)
Weight
• 0.6 lb (0.3 kg)
Power
• Uses AJA power supply model DWP-U-R1, included with purchase
• 100-240V, 50/60 Hz Universal input
• +5 to 20V DC regulated, 8 watts max
Environment
• Safe Operating Temperature: 0 to 40 C (32 to 104 F)
• Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
• Operating Relative Humidity: 10-90% noncondensing
• Operating Altitude: <3,000 meters (<10,000 feet)
