ROI Series Mini-Converter v1.7 39 www.aja.com
Video Outputs
• HDMI
• 1x HDMI loop through connector (with embedded audio, up to 8 channels)
• SDI
• 3G-SDI, SMPTE-259/292/424, 1x BNC
HDCP
• ROI-HDMI does not encode the HDMI output with HDCP encryption
• ROI-HDMI does not accept HDCP input
Audio Inputs
• 1x Analog 3.5mm TRS, 2-channel
• HDMI embedded audio, 24-bit, 8-channel
Audio Output
• SDI embedded audio, 24-bit, 2-channel or 8-channel
User Controls
• USB port used with supplied cable and Mini-Config software application to
configure device via Mac or Windows
Size (w x d x h)
• 5.77” x 4.02” x 0.90” (146.56 x 102.11 x 22.86 mm)
Weight
• 0.6 lb (0.3 kg)
Power
• Uses AJA power supply model DWP-U-R1, included with purchase
• 100-240V, 50/60 Hz Universal input
• +5 to 20V DC regulated, 8 watts max
Environment
• Safe Operating Temperature: 0 to 40 C (32 to 104 F)
• Safe Storage Temperature (Power OFF): -40 to 60 C (-40 to 140 F)
• Operating Relative Humidity: 10-90% noncondensing
• Operating Altitude: <3,000 meters (<10,000 feet)
