ROI Series Mini-Converter v1.7 29 www.aja.com
HDMI Tab Screen (SDI model only)
Click on the HDMI Tab to view and make changes to the following ROI-SDI HDMI
Output settings.
HDMI/DVI
Choose Auto, HDMI, or DVI. When DVI is selected, any audio signals present are
not passed. Choosing “Auto” automatically selects the output mode based on the
attached device’s capabilities.
RGB Range
Choose Auto, SMPTE or Full. Choosing “Auto” automatically selects the RGB
output color range setting.
Bit Depth
Choose from Auto, 8-bit, or 10-bit. Choosing “Auto” automatically selects the bit
depth based on the input video and the attached device’s capabilities.
Color Space
Selects the desired HDMI output video format. Choose from the following:
• Auto - selects the video format based on the input video and the attached
device’s capabilities.
• 4:2:2 YCbCr
• 4:4:4 RGB
• 4:4:4 YCbCr
