ROI Series Mini-Converter v1.7 14 www.aja.com
Chapter 2 – Operation
IMPORTANT: Once the ROI has been configured with Mini-Config, those settings will
continue to be used in stand-alone mode (disconnected from USB) as long as the
input format remains the same. If a different input format is connected, the ROI
will revert to Auto mode. However, if the original input format is re-connected,
the ROI will exit Auto mode and restore the previously configured settings for that
format. ROI Auto Bypass can also be disabled using Mini-Config.
USB Control and Setup—Using AJA Mini-Config
Your AJA Mini-Converter can be used right out of the box for some applications
since it is designed to recognize inputs and perform standard actions
automatically by default. However, to use its full capability, you must use AJA’s
Mini-Config software application for PCs and Macs. This same application can be
used to update to new Mini-Converter software released by AJA.
Acquiring Mini-Config
AJA’s Mini-Config application is available for download from the AJA website.
To download the latest Mini-Config package, which includes the Mini-Config
application, Mini-Converter firmware, and documentation, go to:
Select either the Windows or Mac icon to download the desired version.
Mini-Converter Documentation
Included with the Mini-Config package is a complete set of documentation for
all Mini-Converters supported by Mini-Config. A .PDF of the
Installation and
Operation Guide
for the currently connected Mini-Converter can be accessed from
the Mini-Config UI via the
Help/Manual
drop-down menu.
Documentation for all AJA Mini-Converters that use Mini-Config can also be
accessed directly in the Mini-Config download package Documentation folder,
and via the Documentation icon available on the Mac installer.
Documentation (and firmware) included with the Mini-Config application are the
versions available at the time of distribution. However, Mini-Converter software,
firmware and documentation are updated regularly, so newer versions may exist.
To download the latest documentation for an individual Mini-Converter, go to:
and navigate to the Support webpage of that Mini-Converter.
Installing Mini-Config
PC Installation
To install Mini-Config on a Windows PC:
1. Download the application from the AJA website (select the Windows icon
on the Mini-Config Support webpage).
2. Open the AJA_MiniConfig.zip file
