LG BH5F-M 86" 4K UHD Ultra-Stretch Digital Signage Commercial Monitor - Manual (Page 30)

30
ENGLISH 86BH5F
LCD screen Pixel pitch 0.5595 mm (H) x 0.5595 mm (V)
Power Rated power AC 100-240 V~ 50/60 Hz 2.4 A
Power consumption On Mode: 220 W (Typ.)
Sleep Mode: ≤ 0.5 W
Standby Mode: ≤ 0.5 W
Dimensions (Width
x Height x Depth) /
Weight
Head 2158.3 mm x 348.5 mm x 81.7 mm / 20.5 kg
(84.9 inches x 13.7 inches x 3.2 inches / 45.1 lbs)
Wireless module (LGSBWAC72) Specifications
Wireless LAN (IEEE 802.11a/b/g/n/ac)
Frequency range (MHz) Output power (Max.) (dBm)
2400 to 2483.5
5150 to 5725
5725 to 5850
15
14.5
14.5
Bluetooth
Frequency range (MHz) Output power (Max.) (dBm)
2400 to 2483.5 8.5
• As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is
configured for the regional frequency table.
• For consideration of the user, this device should be installed and operated with a minimum distance of
20 cm (7.8 inches) between the device and the body.
* FCC ID: BEJLGSBWAC72 / IC: 2703H-LGSBWAC72
