PoE Installation Manual
Specifications
Appendix
Tr
oubleshooting
Configuration
Network Clock
Connect
Installation
Intr
oduction
Specifications
Power over Ethernet Relay
Available in the following configurations:
H004526R
Optional Products:
PoE Injector, single port – TMA200
USB Drive with Network Clock Connect Software – H004167B-POE
Features
• Time Zone Management
• Supports Daylight Saving Time
• Power over Ethernet (IEEE802.3af)
• DHCP or Static IP addressing
• Network Clock Connect configuration
• Status LED indicator
• Scheduling - maximum of 100 scheduled events
Specifications
Dimensions: 2.21"h x 4.2"w x .9"d
Weight: .028 lbs.
Power Consumption: PoE, IEEE 802.3af compliant, 1W
Operating Temperature: 41˚ to 131˚F (0˚ to 55˚C)
Operating Humidity: 95% maximum, non-condensing
Accuracy: ±1 second
Relay Specifications
Dry Contacts: NO (or NC-special order) contacts with 2A 30vdc/0.5A 120vac rating and active closure time of 1-59 seconds
Normally open
Common
Activate
+
–
Alarm
System
Comm
Connection Diagram
