3. Start/End Date/Time – The Start and Stop parameters indicate when DST changes occur. These parameters are

available when CUSTOM DST is desired.

• Fixed Day-

• Floating Day-

Note: The default is set using the rule observed by the United States which starts on the second Sunday in March at

2:00 AM and ends on the first Sunday in November at 2:00 AM. The Daylight Saving Time selection may be set to AUTO or

Custom with the following settings:

Hour Bias (± Hour:Min) – The Hour Bias determines the bias during DST. A bias of +1:0 will advance the clocks ahead

1 hour at the start of DST and fall back 1 hour at the end of DST.

Clock Type and Date Mode

•All changes require the Save Settings button to be clicked. For the changes to take effect, the Restart button must be clicked.
1. Clock Type– This displays the clock type. This is not configurable.
2. Date Mode – This is used to select the date mode of the Digital Calendar Clock.
3. Display Duration – This is used to set the duration of the time/date displays for a Digital Calendar Clock. If both time

and date are set to “0”, only the time will be displayed. If date is set to “0” and time is set to anything other than “0”,

only the date will be displayed. If neither time nor date are “0”, the time and date will toggle for the durations

specified.

Other Configurations

•All changes require the Save Settings button to be clicked. For the changes to take effect, the Restart button must be clicked.

1. Unit Name – The Unit Name is used to name and identify each clock. The name may consist of up to 20 alphanumeric

characters.

2. Password – The password field displays the current password. To change the password, enter a new password, click

on the Save Settings button and then click on the Restart button. The default password is clock4u.

3. Brightness – the Brightness selection is used to change the brightness of the time display on the clock. (High, Low,

Sleep, Off). When in the Sleep setting, the time segments of the display will be off. Every 20 seconds the time

segments will display the time for 2-3 seconds in a Low brightness and turn off again.

Note: The Brightness setting is

only available for digital clocks.

Fixed Day
Start Day
Start Time
Stop Date
Stop Time

2nd

Sun

Mar

8th

1st

Sun

Nov

1st

Fixed Day
Start Day
Start Time
Stop Date
Stop Time

2nd

Sun

Mar

8th

1st

Sun

Nov

1st

Fixed Day

Daylight Saving Time

Start Day
Start Time
Stop Date
Stop Time

Hour Bias

2nd

CUSTOM

1 Hours

00 Minutes

Sun

Mar

8th

1st

Sun

Nov

1st
