I.R.I.S. 808 Digital Video Recorder - Manual (Page 84)

The Advanced Network Setup allows the administrator to set advanced network
parameters. If the user is not familiar with network administration, please DO
NOT modify the items in this dialog.
The general operations are as below:
 ▲▼ (Mouse: Left click)
Press these buttons to select the items.
 MENU/ESC (Mouse: Right Click)
Press this button to escape from this screen, and return to Network Setup display.
If the Save dialog is shown, press ENTER to exit and save, MENU/ESC
(Mouse: Right Click) to exit without saving.
Following is a brief description for each item and its specific operations:
 Control Port – the control port for remote access. The default value is 67.
Please follow the Text Input method described in Section 4.1 to modify this item.
 Data Port – the data port for remote access. The default value is 68. Please
follow the Text Input method described in Section 4.1 to modify this item.
 HTTP Port – the HTTP (web page) port for remote access. The default value is
80. Please follow the Text Input method described in Section 4.1 to modify this
item.
 WAP Picture Quality – the WAP picture quality if WAP access is supported for
the DVR. Press +/- buttons to change the value.
 DVR Name – the “DVR Name” used in the “CMS Server” if CMS Server
(described below) is (to be) connected with the DVR. Please follow the Text
Input method described in Section 4.1 to modify this item.
 CMS Server URL #1-2 – the URL (Uniform Resource Locators) for the CMS
Server #1 and #2. The DVR will connect with up to two CMS servers
automatically once it’s running. Please note that with this feature, the DVR
needs not to be a web server, while the CMS server needs to be a web server.
Please follow the Text Input method described in Section 4.1 to modify these
items.
84
