including 1/4/9/16-Window for single DVR and 25/36/49/64 for multiple DVRs. And
the focus window is surrounded by a frame border. In addition to the video windows,
there are different icons on the lower corner and the right corner of the screen for
status display and control.
(The “.L” following the camera title stands for Live
display, “.P” for Playback, and the camera title with white background has detected
motion.)
Note 1: The frame rate is limited by the bandwidth of the network and the pre-
record IPS of the camera (
Note 2: The picture quality depends on the recording resolution and recording
quality of the camera (
).
When the user leaves I.E., he/she may be asked to save changes to files, please click
on OK or Yes to save the changes. The operations and descriptions for these icons are
as below:
In video window, right-click the mouse button to call up Camera/Playback/Print
Dialog. (Left) click on Playback or Camera number to change the window to the
corresponding camera and live/playback mode.
The user may also click on the
“Print” button to print the video to the printer, or “Snapshot” the video. For
software V6.12 or above, the user may double click for 1-Window display.
Click on these icons for 1/4/9/16/25/36/49/64-Window display.
Click on this icon to switch to or return from SEQ display mode.
Click on this icon to toggle between live mode and playback mode for all the video
windows.
