I.R.I.S. 808 Digital Video Recorder User Manual
Page 134

Operating shock
8G, 11ms (20 per five seconds max)
Operating
vibration
With HDD : 5~500Hz, 1.65G (0 to peak)
With SSD : 5~500Hz, 2.7G rms
Weights &
Measures
Dimension
Weight
178(W) x 210(D) x 50(H)mm
2.0 KG (without HDD)
Power
Source
+12 or +24VDC, with acceptable range +9.5~30VDC
Power
Consumption
12W Max. without 12VDC output loading
Power
Delay On/Off
Yes, with configurable timer
Power
Delay Out
30A
Power
12VDC Out
Up to 1.0A for all cameras
Operating Temperature
Operating Temperature
0
o
C ~ +50
o
C, with built-in heater
134
