Internal drives
Internal drives are devices that your server uses to read and store data. The internal drives supported
by your server vary by model.
• Internal storage drive
– In the front:
Your server supports one of the following storage drive configurations:
Drive bay size
Drive bay quantity
Drive type
3.5-inch
4
Hot-swap, SATA or SAS
Hard disk drive or 2.5-inch solid-state drive
2.5-inch
12
Hot-swap, SATA or SAS
Hard disk drive or solid-state drive
Note: You can install a 2.5-inch solid-state drive into a 3.5-inch-drive bay. For more information, see
“Installing a 2.5-inch solid-state drive into a 3.5-inch hard-disk-drive bay” on page 122.
– In the rear: (for server models with the four 3.5-inch drives only)
Drive bay size
Drive bay quantity
Drive type
2.5-inch
2
Hot-swap, SATA
Hard disk drive or solid-state drive
Notes:
– SATA is the acronym for Serial Advanced Technology Attachment.
– SAS stands for Serial Attached SCSI (SCSI is the acronym for Small Computer System Interface).
– You can install SATA hard disk drives, SAS hard disk drives, and solid-state drives into the same server.
The following server models also are available:
– Server models without hard disk drives or solid-state drives
– Server models without hard disk drives, solid-state drives, backplanes, AnyRAID adapters, and related
cables
• Optical drive
– One slim SATA optical drive in some models
For the location information about the internal drives or drive bays, see “Server components” on page 25.
Expansion slots
• Two riser card assembly slots on the system board
• One or two PCI Express (PCIe) card slots on the riser card
• One or two AnyFabric slots at the rear of the server
For detailed information, see “Rear view of the server” on page 21.
.
