AUXILIARY WATER TANK WITH PUMP
86037400 09/06/07
5-48
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86277830 00-000072
4
SCR, 3/8-16 X 2” HXHD
2
86277850 00-000337
1
SCR, 10-32 X 1” SOCHD SST
3
86270330 02-000066 4 FLATWASHER,
1/4
4
86177020 03-000113
4
CLAMP, HOSE #12 SST
5
86280550 09-805446
1
HOSE, 5/8 ID BLU X 55”
6
86280290 09-805278
1
HOSE, 3/4 ID WTR X 3”
7
86280420 09-805357
1
HOSE, 3/4 ID WTR X5.5”
8
86280140 09-805406
1
HOSE, 5/8 ID BLU X 30 1/2
9
86180170 11-800041
2
ELL, STREET 1/2 BR MACH
10
86180210 11-800275
1
ELL, ST 3/8 BR
11
86191600 11-800283
1
RED, 1/2FP X 3/8P BR
12
86176400 11-800432
1
CAP, WATER BOX
13
86188470 11-800524
1
NIP, 1-1/2XCL PVC (SCH80)
14
86181320 12-800095
1
FTTG, BRB 3/4PX3/4H BR
15
86181360 12-800269
1
FTTG, BRB 1/2 X 5/8H BR
16
86181400 12-800345
2
FTTG, BRB 3/8P X 5/8 BR
17
86179710 13-806008
1
DISCONNECT 3/8F X 3/8FP
18
86179630 13-806009
1
DISCONNECT 3/8M X 3/8FP
19
86180900 14-806553
1
FILTER, DEMAND PUMP
20
86195010 15-808080
1
VALVE, BALL PVC 1-1/2FP
21
86192380 16-808164
1
SEAT, FLOAT VLV TM
22
86173820 16-808216
1
ARM, PIVOT-FH VLV
23
86174610 16-808217
1
BDY, FLOAT VLV
24
86174540 19-807014 1 BALL,
FLOAT
25
86190740 41-905049
1
PMP, WTR BOOSTER FLOJET 2
26
86190170 50-500511
4
PLATE, INSTALL MT
27
86189010 52-501706
1
NUT, FLOAT VALVE
28
86028860 52-800314
1
PISTON, FLOAT VLV PISTON
29
86181150 54-501715
1
FLOAT ROD, TM
30
86186120 48-809423
1
KIT, PORT DEMAND PUMP
31
86180010
31100
1
ELBOW, 1.5 STREET PVC MP X FP
32
86270770 57006 2
NUT,
1/4-20
HEX
33
86270990
57090
1
NUT, 10-32 HEX NYLOCK SS
34
86005770
57119
4
NUT, 3/8-16 HEX NYLOCK
35
86274750
70270
4
SCR, 1/4-20 X 3/4 HHCS PLTD
36
86010780
87162
4
WASHER, 1/4 SPLIT LOCK PLTD
37
86279510
87171
8
WASHER, 3/8 FLAT
38
86031000
790617
1
TANK, FRESH WATER 70GAL
39
86057170
790666
2
STRAP, WTR TNK HOLD DOWN
40
86177060 03-000246
3
CLAMP, HOSE #8 SST
