CONTROL PANEL-UPPER
86037400 01/12/08
5-6
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86195050 15-808106
1
VALVE, METER 1/8FP
2
86177660 12-800065
2
CONN, 1/8P X 1/4T
3
86247720
56032
1
NIPPLE, 1/8 CLOSE
4
86017360
140675
1
BRKT, FLOW METER
5
86297070
-
1
VALVE, 3-WAY BALL 1/8P
6
86180140 11-800014
1
ELL, STREET 1/8 BR
7
86181300 12-800093
3
FTTG, BRB 1/8P X 5/16H
8
86255920
73811
2
STANDOFF, 3-32 X 1/2 HEX NYL
9
86274290
70162
4
SCR, 10-32 X 3/8 PPHMS SS
10
86279470
87165
4
WASHER, #10 SPLIT LOCK PLTD
11
86180380 12-800101
1
ELL, 1/4FP X 1/4T BR
12
86180350 12-800035
1
ELL, 1/4FP X 1/4T BR
13
86049750
61457
1
PNL, FRNT, LGND XL, PC
14
86246890
54092
1
METER, 0-60VDC HOUR
15 86270330
02-000066 4 FLATWASHER,
1/4
16
86010780
87162
4
WASHER, 1/4 SPLIT LOCK PLTD
17
86274750
70270
4
SCR, 1/4-20 X 3/4 HHCS PLTD
18
86181960
36229
1
GAUGE, TEMP, DATCON
19
86175510 33-900163
2
BREAKER, CIRC 20A
20 86186020
32-900174 1 KEYSWITCH
21 86193760
32-900206 1 SW,
RTRY W/BYPASS NON-ILL
22
86193750 32-900205
1
SW, RTRY NON-ILLUM TM
23
86181930
36225
1
GAUGE, 0-1500 PSI
24
86181950
36227
1
GAUGE, VACUUM 30” HG
25
86186640
500835
1
LABEL, CONTROL PNL LEGEND XL
26
86186620
500834
1
LABEL, CHEM PNL XL
27 86181170
18-808513 1 FLOWMETER,
1/8FP
28 86176120
49-802518 1 CABLE,
CHOKE
29
86177540
791081
1
CNTRL, THRTL, BLZRXL, CLR/CLNR
1000163020
30 86024760 790742 2 PAD,
PNL
31
86186640
500837
1
LABEL, FRNT HD, LXL, PC
32
86191740 35-900188
1
RELAY, ENG SHTDWN
33
86175490 33-900161
1
BREAKER, CIRC 30A
34
86270920
57049
4
NUT, 6-32 HEX NYLOCK SS
35
86175680
140702
1
BRKT, WIKA MOUNTING
36
86183000
790716
1
HARN, LEGEND XL
NOT SHOWN
37 86136310 57086 4 NUT,
M5
HEX
38
86005720
57106
1
NUT, 8-32 W/STAR WASHER
