86037400-pg-5-8_5-9, Engine – Prochem Legend XL User Manual
Page 47
ENGINE
86037400 05/22/08
5-8
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86186430 42-902299
1
KOH ELEM, AIR CLNR #470830
2 86179670 790677 1
DRIVESHAFT,
FRONT KOHLER 20HP
3 86049230
54-500412 1
KEY. 1/4 SQ X 1.88
4 86191280 790719 1
PULLEY,
1B36SH
5 86185400 790720 1
HUB,
SH1
6
86273180 00-000078
3
SCR, 1/4-20 X 1” HXHD GRD8
7
86275830
70549
4
SCR, M8 X 25 HHCS GR8 PLTD
8
86137310
87098
4
WASHER, M8 SPLIT LOCK
9 86186360
42-902289 1
KOH SPK PLG#1213202
10
86186400 42-902296
1
KOH FLTR, FUEL #2505003
11
86176990 03-000065
4
CLAMP, HOSE #4 SST
12
86280150 09-805447
1
HOSE, FUEL 1/4 X 9
13
86179930
790606
1
EL, 90DEG 1/8NPT X 1/4HB
14 86190550
12-800062 1 PLUG,
1/2T
15
86183600 10-805291
1
HOSE, HP 3/8 X 10 (3/8 X 1/2FT)
16
86186320 42-902277
1
KOH FLTR, OIL #1205001
17 86191030
44-802212 1 PULLEY,
2TA54
18 86185310
44-802182 1 HUB,
P2X1-1/8
19
86273440 00-000340
3
SCR, MACH 5/16-18 X 1” BG8
20
86182730
790626
3
GSKT, EXHST, KHLR 25HP
21
86279130
87083
2
WASHER, 5/16 SPLIT LOCK PLTD
22
86005650
57031
2
NUT, 5/16-18 HEX
23 86136280 57054 4 NUT,
M8
24
86137310
87098
4
WASHER, M8 LOCK
25
86187230
790710
1
MNFLD, ENG EXH, KHLR, XL
26
86186380 42-902293
1
KOH CARB # 2485335S
27
86186410 42-902297
1
KOH PMP, FUEL PULSE #24393165
28
86180760 40-902152
1
ENG, KOHLER 20 HP
29
OPEN
30
OPEN
31
OPEN
32
OPEN
33
86005770
57119
4
NUT, 3/8-16 HEX NYLOCK
34
86279510
87171
8
WASHER, 3/8 FLAT
35
86277830 00-000072
4
SCR, 3/8-16 X 2” HXHD
36
86277930
70119
1
SET SCREW, 1/4-20 X 3/8 KCP
37
86254140
791176
1
SOLENOID, KOH# 25-435-05-S
-
86177130
791083
1
CLAMP, CABLE, THRT/CHOKE
- 86277890 70856 1
SCREW, M5-8 X 25MM STL, ZNC
(CLAMP SCREW)
