86037400-pg-5-38_5-39, Stair tool-optional – Prochem Legend XL User Manual
Page 77
STAIR TOOL-OPTIONAL
86037400 02/16/07
5-38
REF PART NO. PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
86285350
78519
-
TL, STAIR, LNG, TM DJ (80015)
COMPLETE
-
86285290
78521
-
TL, STAIR, SHT, TM (80015)
COMPLETE
1A
OPEN
- -
-
1B
OPEN
- -
-
2
86198080
52-501576
1
BODY, WD HDL PORT
3
86198170
52-501577
1
HOLD DOWN, WD HDL PORT
4
86265730
04-000053
2
TIE, CABLE 8” WHT
5
86183710
10-805330
1
HOSE, 3/16X13-3/4 (1/8PX1/4)
5A
86184000
10-805397
1
HOSE, 3/16X7-1/2 (1/8P X 1/4F)
6
86194410
17-803002
1
TIP, SPRY 9502X1/8P SST
7
86273310
00-000282
2
SCR, CAP 1/4-20 X 1-1/4 SOC
8
86177650
12-800060
1
CONN, 1/4P X 1/4T BR
9
86192030
00-000317
3
SCR, CAP 10-32X1-1/4 SOCH
10
86270990
57090
3
NUT, 10-32 HEX NYLOCK SS
11
86174120
61-950496
1
ASSY, EXTRCTR VLV
12
86247680
56015 1
NIPPLE,
1/4
HEX
13
86005580
56012
1
NIPPLE, 1/4 FPT QD
14
86194650
52-501619
1
TRIGGER, WD VLV
15
86280020
09-805359
1
SLEEVE, WD HDL 9.5
15A
86040950
09-805504
1
SLEEVE, STAIR TL HDL 7-1/8
16
86183160
16-808229
1
HOLDER, VLV STEM-EXTRCTR VL
17
86189520
43-810063
1
O-RING, .551 ID .691 OD
18
86192410
16-808228
1
SEAT, EXTRCTR VLV
19
86193360
16-808189
1
STEM, EXTRCTR VLV
20
86174500
43-810064 1
BACK-UP,
.250DIA
21
86189510
43-810062
1
O-RING, .114 ID .254 OD
22
86193200
16-808190 1
SPRING,
EXTRCTR
VLV
23
86174630
52-501590
BODY, EXTRCTR VLV
-
86178970
48-941163
DECAL,
STAIR
TL
NOT SHOWN
-
86186160
66-808169
KIT, REP-WD VLV
NOT
SHOWN
INCLUDES
PARTS 16-19
& 20-22
