VACUUM PUMP
86037400 08/20/08
5-10
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86177010 03-000112
2
CLAMP, HOSE #8
2
86184490 09-805478
1
HOSE, VAC 2.88 X 2.5 BLK
3
86188500 54-501593
1
NIP, VAC EXH OUTLET
4 86175030
44-802250 2
BELT, AX38 GOODYEAR MATCH
1000124348 WAS 44-802314
5 86191030
44-802212 1
PULLEY,
2TA54
6 86185320
44-802196 1
PULL,
AKG1H
7
86273440 00-000340
3
SCR, MACH 5/16-18 X 1” GR8
8
86005770
57119
4
NUT, 3/8-18 HEX NYLOCK
9
86279510
87171
5
WASHER, 3/8 FLAT
10
86270320 02-000057
2
FLATWASHER, 1/2” HEAVY
11 86273400
00-000323 2 SCR,
1/2-13 X 3 1/2 HHCS FULL THDS
12
86046120
790874
1
BRKT, VAC ADJ ASM XL
13
86190700 41-905021
1
PMP, VAC 4M-L
14
86271070
57114
2
NUT, 7/16-24 HEX
15
86193230 04-000091
1
SPRING, VAC REL VLV
16
86180600 52-501573
1
ELL, VAC REL VLV
17
86311600
-
1
WASHER, VAC REL VLV #4 VAC
18
86179580 43-807074
1
DIAPHRAM, VAC REL VLV
19
86177640 12-800059
2
CONN, 1/8P X 1/4 POLY BR
20 86271740 57249 2 NUT,
1/2-13
JAM
21
86273320 00-000284
1
SCR, CAP 7/16-14 X 4 HXHD
