WAND-QUAD JET-OPTIONAL
86037400 02/16/07
5-34
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
- 86285570 89238
-
WAND, TM, QJW (95015) PC
COMPLETE
- 86285580 89239
-
WAND, TM, QJW (9502) PC
COMPLETE
- 86285560 89237
-
WAND, TM QJW (9501) PC
COMPLETE
- 86285540 89235
-
WAND, TM, QJW, (9501) NO
DECAL
COMPLETE
1 86005580 56012
-
NIPPLE, 1/4 FPT QD
2 86177860
17-803010
1
CONN, 1/4P X 11/16-16M
3 86195570
17-803006
1
WASHER, NYLON
4 86193490
14-806512
2
STRAINER, JET 50 MESH
5 86177870
17-803036
1
CONN, 1/4FP,11/16-16R BR
6 86247680 56015
1
NIPPLE, 1/4 HEX
7 86280020
09-805359
1
SLEEVE, WD HDL 9.5
8 86194650
52-501619
1
TRIGGER, WD VLV
9 86192030
00-000317
3
SCR, CAP 10-32X 1-1/4 SOCH
10 86270990 57090
3
NUT, 10-32 HEX NYLOCK SS
11 86174120 61-950496
1
ASSY, EXTRCTR VLV
12 86177650 12-800060
1
CONN, 1/4P X 1/4T BR
13 86183970 10-805387
1
HOSE, 3/16 X 43-1/2 (1/8P X 1/4)
14 86265730 04-000053
3
TIE, CABLE 8” WHT
15 86273310 00-000282
2
SCR, CAP 1/4-20 X 1-1/4 SOC
16 86198160 52-501569
1
HOLD DOWN, WD HDL
17 86182840 791150
1
BODY, WD HDL
18 OPEN
-
1
-
19 86190180 11-800206
2
PLUG, 1/8 SOCHD BR
20 86043300 56-501966
1
ASSY, L S-BEND MNFLD
21 86273450 00-000347
4
SCR, CAP 10-24 X1/4 SOCHD
22 86279470 87165
4
WASHER, #10 SPLIT LOCK
23 86194400 17-803001
4
TIP, SPRY 95015X1/8P SST
89238
23A 86194410 17-803002
4
TIP, SPRY 9502X1/8P SST
89239
23B 86194450 17-803018
4
TIP, SPRY 9501X1/8P SST
89237
89235 (NO DECAL)
24 86043310 56-501986
1
ASSY, RT S-BEND MNFLD
25 86177710 12-800322
2
CONN, 1/8PX1/4T COMP BR
26 86174030 56-501967
1
ASSY, S-BEND MNFLD
27 86183160 16-808229
1
HOLDER, VLV STEM-EXTRCTR
VL
28 86189520 43-810063
1
O-RING, .551 ID .691 OD
29 86192410 16-808228
1
SEAT, EXTRCTR VLV
30 86193360 16-808189
1
STEM, EXTRCTR VLV
31 86174500 43-810064
1
BACK-UP, .250 DIA
32 86189510 43-810062
1
O-RING, .144 ID .254 OD
33 86193200 16-808190
1
SPRING, EXTRCTR VLV
34 86174630 52-501590
1
BODY, EXTRCTR VLV
- 86179020
48-941186
1
DECAL, WD HD (CAST SS)
NOT SHOWN
- 86186160
66-808169
KIT, REP-WD VLV
NOT SHOWN
IINCLUDES PARTS 27-
29 & 31-33
