PRESSURE REGULATOR & TEMPERATURE BYPASS
86037400 02/16/07
5-18
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86173460
790106
1
ACCUMULATOR , 250PSI CAT 6026
2 86187250
790713
1
MANIFOLD, PRESSURE REG
3 86188110
11-800128
2
NIP, HEX 1/4 SST
4 86191630
15-808081
1
REG, PRE W/O INNER SPRING
5 86180040
790722
1
ELBOW, 1/4MP X 1/2H 90DEG
6 86188390
11-800429
1
NIP, HEX 3/8 SST
7 86192210
14-806549
1
SCREEN, CHECK VALVE
8 86195030
15-808094
1
VALVE, CHECK
9 86180360
12-800040
2
ELL, /18P X 1/4T BR
10 86180410
12-800225
1
ELL, 3/8P X 1/2T BR
11 86174010
15-808131
1
MNFLD, CHK VLV
INCLUDES 7&8
12 86177660
12-800065
2
CONN, 1/8P X 1/4T
13 86180450
12-800347
1
ELL, 3/8P X 1/2T 45 DEG BR
14 86177680
12-800141
1
CONN, 1/2P X 1/2T
15 86279400
87151
2
WASHER, 1/4 SPLIT LOCK BLK
16 86275460
70481
2
SCR, 1/4-20 X 3/4 BHCS BLK
17 86278970
87012
1
WASHER, 7/16 STAR
18 86002450
22015
1
COUPLER, 1/4 QD
19 86195050
15-808106
1
VALVE, METER 1/8FP
20 86278970
87012
1
WASHER, 7/16 STAR
21 86186040
16-808193
1
KIT, REPAIR PRESSURE REG
